HDMI Audio Extractor
In stock
The HD/MH-HD+A audio extractor supports 3D, 4KX2K, ARC and allows one HDMI or one MHL source input and one HDMI output connected to one HD Display (TV or Projector) and extracts the audio to one SPDIF audio out+One LR Stereo audio out.
Product code: HD/MH-HD+A
R839.00 R1,014.00
In stock
Key Features:
- Supports 3D, Full HD 1080P, and 4K×2K resolution
- HDMI/MHL audio extractor with HDMI output
- Extracts audio to SPDIF and L/R stereo outputs
- Supports ARC (Audio Return Channel) function
- HDMI and MHL dual-mode operation
- SPDIF + RCA L/R analog audio output support
- Audio mode selection: ADV / 2.0CH / 5.1CH
- Allows audio and video signal separation
- No signal or sound quality loss
- LED status indication for source and output connection
- Easy plug-and-play installation
- Compact and user-friendly design
- Suitable for TVs, projectors, AV amplifiers, gaming consoles, and media players
- Requires DC 5V/1A power supply
Additional Details
| Weight | 300.0 g |
|---|---|
| Dimensions | 14.8 × 12.0 × 6.2 cm |
| Barcode | 6009532404717 |
| Brand | Space |
| Model No | HD/MH-HD+A |
| HDMI resolution | 24/50/60fs/1080p/1080i/720p/576p/57 6i/480p/480i |
| Support video color format | 24bit/deep color 30bit, 36bit |
| Audio output | L/R+SPDIF |
| Max bandwidth | 300MHz |
| Max baud rate | 9.0Gbps |
| Input/Output TMDS signal | 0.5~1.5Volts p-p (TTL) |
| Input/Output DDC signal | 5Volts p-p (TTL) |
| Input cable distance | ≤15m AWG26 HDMI standard cable |
| Output cable distance | ≤20m AWG26 HDMI standard cable |
| Max working current | 500mA |
| Power adapter format | Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A |
| Operating Temperature range | -10 to +55°C |
| Storage Temperature range | -20 to +60°C |
| Operating Humidity range | 10 to 90%RH (No Condensation) |
| Storage Humidity range | 5 to 95%RH (No Condensation) |
| Dimension (L x W x H) | 84.5 x 61.8 x 21 mm |
| Weight | 135g |
Downloads
