-23%
| Weight | 0.0 g |
|---|---|
| Dimensions | 0.0 × 0.0 × 0.0 cm |
| Brand | JOHANSSON |
| 9656 | ||
|---|---|---|
| Inputs | – | TERR + HOR + VERT |
| Outputs | – | TERR + HOR + VERT |
| Taps | – | TERR + HOR + VERT |
| Frequency range TERR | MHz | 5 – 862 |
| Frequency range SAT | MHz | 290 – 2400 |
| Trunk Loss TERR | dB | 1,5 – 2 |
| Trunk Loss SAT | dB | 2 |
| Tap Loss TERR | dB | 13 |
| Tap Loss SAT | dB | 11 |
| Return Loss | dB | 12 |
| DC pass all ports | – | Yes, 1 A |
| Dimensions | mm | 130 x 130 x 50 |
| EAN | – | 5404041101972 |
